Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.
The proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride.
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.
Sizes |
XS S M L |
Colours |
Shale Green |
Frame |
ALUXX-grade aluminium, 12x142mm thru-axle, flat mount disc, flip chip – dropout |
Fork |
Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, flat mount disc |
Shock |
N/A |
Handlebar |
Giant Contact XR D-Fuse, 31.8mm, 5-degree back sweep, flare drop, alloy XS: 400mm, S: 400mm, M: 420mm, L: 420mm |
Stem |
Giant Contact, +/- 8 degree, alloy XS: 50mm, S: 60mm, M: 70mm, L: 80mm |
Seatpost |
Giant Contact D-Fuse, alloy, 14mm offset |
Saddle |
Liv Approach |
Pedals |
N/A |
Shifters |
Shimano Sora, 2x9 |
Front Derailleur |
Shimano Sora |
Rear Derailleur |
Shimano Sora, long cage |
Brakes |
Tektro MD-C550 mechanical, Giant MPH rotors [F]160mm, [R]160mm |
Brake Levers |
Shimano Sora |
Cassette |
Shimano HG400, 11x34 |
Chain |
KMC X9 with Missing Link |
Crankset |
FSA Vero Pro, 32/48 XS: 165mm, S: 170mm, M: 172.5mm, L: 172.5mm |
Bottom Bracket |
FSA cartridge |
Rims |
Giant S-X2 Disc wheelset alloy |
Hubs |
Giant alloy 12mm thru-axle |
Spokes |
stainless steel |
Tyres |
Giant CrossCut AT 2 700x38c tubeless |
Max Chainring Size |
Shimano Road 2x 56-43. GRX 2x 48-31, 1x 46T. SRAM Road 2x 56-43, 1x 52T, SRAM Wide 2x 43-30, 1x 46T |
Extras |
Factory tubeless set up, ISC clamp |
Weight |
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight but in reality weight can vary based on size finish hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
